Product Description
This listing is for a B-Stock product. B-Stock refers to an item that could have been purchased and returned in not new condition, old inventory, cosmetically damaged in shipping or warranty repaired. These items are sold as is and offer no refunds. All items are tested and verified to be fully functional, with only cosmetic issues. Cosmetic issues may include: scratches, scuffs , dents or cosmetically broken parts. We offer a 5-Day plug and play warranty starting from day of delivery. Image in listing may not be exact item you are buying but for reference of other B-Stock item or new item.
Disclaimer: This amplifier will require an additional charging system to run efficiently. It will run without the additional charging system but you run the risk of damaging the amplifier and/or not getting the optimum power out of it. The additional charging system includes the big 3 upgrade, a high output alternator, as well as adding an AGM or Lithium car audio battery. All of our amplifiers are age tested for an hour before going into stock.
- Single channel
- 2300 Watts RMS @ 1 Ohm
- Class D
- 1 Ohm stable
- 1/0 AWG power inputs
- Charging system upgrades necessary
Tags: 2250 watt mono amplifier
| Model | S1-2250 |
|---|---|
| Class | Class D |
| Channels | 1 Channel |
| Working Voltage | 8.5 V - 16 V |
| Maximum Amperage | 225 Amps |
| Power @ 4 Ohm 14.4V | 800 Watts RMS |
| Power @ 2 Ohm 14.4V | 1300 Watts RMS |
| Power @ 1 Ohm 14.4V | 2300 Watts RMS |
| Frequency Response | 10 Hz - 200 Hz |
| S/N Ratio | Greater than 80 |
| Damping Factor | Greater than 100 |
| Input Sensitivity | 5 V - 0.15 V |
| Subsonic Filter | 10 Hz - 50 Hz |
| Low-Pass Filter | 20 Hz - 200 Hz |
| Dimensions in (LxWxH) |
19.6 x 7.8 x 2.2 |
