Product Description
? Sky High Car Audio SHCA5500.1 – All-Purpose Power with Sky High Flexibility
Rethinking the amplifier: The most customizable and vertical amp EVER. It’s not just a statement; it’s facts.
| Korean Built | Class D | 0.5Ω Stable | Individually QC Tested | Ultra Fast Switching | Balanced Input Circuit | Onboard Synchronizer | Strappable | 3 Levels of Modular Cooling | Premium Customization in Color, Mounting & Appearance | Acrylic Back | Expansion-Ready |
⸻
? More Power. More Confidence.
The SHCA5500.1 takes everything you love about the 3500.1 and scales it up for more dynamic range, more headroom, and more output potential—without compromising on footprint or flexibility. It’s a versatile amp designed for both powerful daily builds and serious front-stage systems that demand control and cooling under stress.
•True 0.5 Ohm Stability
Warrantied and tested to perform under heavy load in real-world conditions.
•17.0vdc Max Operating Voltage - rated at 13.2vdc @ 1 ohm
•1-Year Manufacturer Warranty
Covers manufacturer defects including 0.5Ω operation from date of purchase.
•Korean Engineered & Assembled
Designed by engineers from scratch, using world class parts and optimized with Sky High modular features.
⸻
? Dimensions
•20.47” (L) × 9.92” (W) × 3.13” (H)
Slightly larger than the 3500.1 but shares the same width, height, and accessory compatibility.
⸻
❄️ Efficiency & Airflow Built In
•High-efficiency circuit layout reduces internal heat and stress
•Standard acrylic backplate with internally mounted cooling fan improves reliability and extends performance during high-demand use
•Designed for long play sessions, demo events, and high-output daily systems without heat-based drop-off
⸻
? Customization That Stands Alone
? Flippable Branding System
•Diamond-cut aluminum Sky High logo and aluminum model number plates are fully reversible for clean orientation in any mounting position
? Modular Center Panel
•Drop-in customizable overlays available custom or in standard form (sold separately) examples of materials:
•Forged carbon
•Mirror stainless
•Paint-matched aluminum
•Acrylic/plexi light-up options
•No adhesives, no fabrication—just swap and bolt on
⸻
? Power Input Flexibility
⚡ Input Expansion Kits (Sold Separately)
•Add more 12V power delivery points for high-demand builds
•Available in:
•Cast aluminum
•CNC’d aircraft-grade aluminum
•Copper
? Ring Terminal Adapters (Sold Separately)
•Ideal for tight fitments and clean panel work
•Bolt-on design ensures secure, high-conductivity connections
⸻
? Cooling System Expandability
? Passive Cooling Add-Ons (Sold Separately)
•Slide-in extruded aluminum heat sink overlays increase surface area up to 25%
•Available in 5 color options as well in raw aluminum for custom finish work including plain, powder, gold/chrome/copper/ rose gold dip, polish or other high end finishes all available.
- Non-anodized coatings will affect cooling potential of aluminum.
? Active Cooling (Sold Separately)
•Push/pull fan kits mount to the extruded heatsink extensions and plug into (4) onboard 12V outputs
•Optional thermal bridges link airflow between linked amps
? 2026 Water Cooling Ready
•Bolt-on water-cooled heatsink system (in development) will include pump, radiator, and lines. Optional tank sold separately.
⸻
?️ CAT6 Remote System
•Link up to 12 SHCA amps
•Control gain, subsonic, LPF, and phase control all from a single unit.
•Monitor temp or voltage of amps
•Fully compatible with Sky High Smart Bass Knob
⸻
? Mounting Options for High-End Builds
As with every amp in the SHCA line this amp is designed for modular mounting options to accommodate any system layout.
•Bracket kits (sold separately) allow:
•Stacking
•Vertical mounting (adjustable mounts and static mounts available)
•Floating wall installs
•Side-by-side linking
•Proprietary Slide-lock channels in the heat sink allow for bracket setup
Available in:
•Extruded aluminum (lightweight, modular)
•Cast aluminum (durable and economical)
•Machined billet aluminum (show-grade)
**Optional footless endcaps allow for smooth flush mounting in clean-wall or rail-based installs
⸻
? SHCA5500.1 – All-Purpose Power with Sky High Flexibility
From demo dailies to pro-level show builds, the SHCA5500.1 gives you clean power, complete control, and system-matching flexibility—all in a size that fits almost any install.
