Product Description
This listing is for a B-Stock product. B-Stock refers to an item that could have been purchased and returned in not new condition, old inventory, cosmetically damaged in shipping or warranty repaired. These items are sold as is and offer no refunds. All items are tested and verified to be fully functional, with only cosmetic issues. Cosmetic issues may include: scratches, scuffs , dents or cosmetically broken parts.We offer a 5-Day plug and play warranty starting from day of delivery. Image in listing may not be exact item you are buying but for reference of other B-Stock item or new item.
The SoundQubed Q4-150 is the most versatile amplifier in the lineup. You can use it to power the whole car stereo system, mids, highs and a subwoofer from one amplifier!
Featuring a four-channel class A/B output, the Q4-150 offers superb sound quality and enough power to drive arrays of speakers. Its variable high and low pass filters can be used in a bandpass configuration so you’re able to tune and define your sound.
If you’re driving subwoofers with this multiple channel amplifier, take advantage of the bass boost for a low end so thick you can eat it for dinner. The included remote gain control knob comes complete with a clipping indicator so you can keep an eye on your levels while your ears have fun absorbing the sounds.
The Q4-150 is stable at 2 Ohm in stereo and 4 Ohm in mono mode. Its bridge channels can send even more power to select speakers.
Four-way protection circuits and MOSFET switching devices are there to make sure you’re able to enjoy your Q4-150 for years to come.
| Model | Q4-150 |
| Class | Class A/B Amplifier |
| Channels | 4 Channel |
| Working Voltage | 9V - 16V |
| Fuse Rating | 120A (external) |
| Power @ 4 Ohm 14.4V | 440 x 2 (Mono) Watts RMS |
| Power @ 2 Ohm 14.4V | 220 x 4 Watts RMS |
| Power @ 4 Ohm 14.4V | 150 x 4 Watts |
| Frequency Response | 20 Hz - 30kHz |
| S/N Ratio | 105dB |
| Damping Factor | Greater than 200 |
| Input Sensitivity | .2V- 8V |
| High Pass Filter | 20Hz - 5kHZ |
| Low-Pass Filter | 50 Hz - 5kHz |
| Bass Boost | 0 - 18dB @ 45Hz |
| Dimensions in (LxWxH) | 22 x 9.5 x 2.63 |
| Dimensions MM (LxWxH) | 558.8 x 241.3 x 66.8 |
